Technical Specifications

Light source:

3x20W led RGB + Lime – Full Color
LED lifespan: > 50.000h
LED refresh frequency: >  600Hz a 15 KHz flicker-free

Optic system:

Beam Angle: 10°
Illuminance: 875lux @ 5m (full on)

Color system:

RGB + Lime – Full Color
Infinite chromatic possibilities

Effects:

Linear dimmer 0-100%
Electronic strobo, pulse, random
Color macros selectable via DMX
Auto mode with 8 programs selectable from the display
CCT: White presets with 11 macros
Color mode with 44 color macros
4 Dimmer curves: Linear, Exp, Log, S-Curve

Control and programming:

4 DMX configurations available: 3/4/6/12 channels
Built-in wireless DMX transceiver
Reset function via DMX

Structure and cabinet:

High resistance 6063 die cast aluminum housing
Graphic LCD color display with touch buttons
Front tempered glass
IP65 rating
Convection cooling system without fans
Frost filters included: 30°
Floor and suspension bracket included
Antiglare ring inlcuded

Power supply

Input Voltage: 12 VDC for standard use and battery recharge
Rechargeable internal Li-Ion battery: 12VDC – 7.8Ah
Runtime battery: ~ 2 hrs (full ON – Boost power mode)
Runtime battery: ~ 11 hrs (Color change – Boost power mode)
Charging cycle: ~ 5 hrs (Projector turned off)
Power adapter 12 VDC included

Weight and dimensions

Net weight: 1,4 kg (accessories not included)
Dimensions: 119h x 120diam mm
